CEM-301 AC & DC Motor Technology Trainer

    DETAILS

      • This trainer is designed to meet the operation training of various electric machines, covering a wide
         range for electrical machine control technologies for both AC and DC motors and generators.
      • All motors and generators come with standard aluminium profile mounting base, coupling and foot
         pad   for easy experimental combination via universal shaft couplings of  same height.
      • The frame adopts standard aluminum profile with modular experiment panel design, thus, making it
         easily to build different experiment combination on the flexible two-layer structure. All the upper parts
         are removable including the experiment  module, power supply module and frame support.
      • All terminals are led out on printed composite panel with 4mm safety socket and connected by
         full sealing sheathed pluggable connector. The complete unit is movable with lockable truckles on
         bottom and available for training content extension by using other CHOIEO modular electrical units.

    > TRAINING CONTENT
        DC Motor
      • Acknowledge of motor / instrument /  rheostat
      • Cold resistance measurement of DC  motor/generator armature winding
      • Starting / speed regulation / direction  control of DC separately excited motor
      • DC generator no-load / external /  regulating characteristics
      • DC shunt generator self-excitation and  external characteristics
      • DC compound generator distinction and  external characteristics
      • DC shunt motor operating / mechanical /  regulation characteristics and dynamic braking
      • DC series motor operating / mechanical /  regulation characteristics
        Asynchronous Motor
      • Three phase squirrel cage asynchronous  motor working characteristics
           Motor slip ratio measurement
           Stator winding cold resistance  measurement
           Stator winding head/tail end judgment
           No-load / short circuit / load  experiment
      • Three phase wound rotor asynchronous  motor starting / speed regulation and torque test
      • Single phase resistor starting  asynchronous motor
           Stator winding cold resistance  measurement
           No-load / short circuit / load  experiment
      • Single phase capacitor starting  asynchronous motor
           Stator winding cold resistance  measurement
           No-load / short circuit / load  experiment
      • Single phase capacitor running  asynchronous motor
           Stator winding cold resistance  measurement
           Effective turns ratio measurement
           No-load / short circuit / load  experiment
      • Dual speed asynchronous motor four /  two-pole working characteristics testing
        Synchronous Motor
      • Three phase synchronous generator running  characteristics
           Armature winding cold resistance  measurement
           No-load / three phase short circuit  experiment
           External characteristics under  resistance load
          Regulation characteristics under  resistance load
      • Three phase synchronous motor
           Asynchronous starting
           V type curve under different output  power
           Working characteristics measurement
      • Parametric measurement of three phase  synchronous generator
           Synchronous reactance measurement
           Negative sequence reactance and  resistance measurement
           Zero sequence reactance measurement
           Subtransient / transient reactance  measurement
        Measurement of Motor  Mechanical Characteristics
      • Mechanical characteristics of separately  excited DC motor under different running states
           Mechanical characteristics under  electric running and regenerative braking state
           Mechanical characteristics under  electric running and reverse braking state
           Mechanical characteristics under  dynamic braking state
      • Mechanical characteristics of three phase  asynchronous motor under different running states
           Mechanical characteristics under  electric running and generating braking state
           Mechanical characteristics under  electric running and reverse braking state
           Mechanical characteristics under  dynamic braking state
           No-load loss curve
